Description
Model Name/No. – AMI-A1 Advance
STEEL QUALITY 304 MEDICAL GRADE STAINLESS STEEL
Product Details:-
| Model Name | AMI A1 Advance |
| Floor Locking System | MANUAL |
| Is It Portable | YES |
| Leg Rest Up Down | 0 DEGREE TO 90 DEGREE |
| Back Rest Up Down | +-60 DEGREE |
| Features | Height Adjustable, Rotating, Tilting |
| Table Width (in mm) | 520 MM |
| Table Length (in mm) | 1900 MM |
| Surgery | Major Surgery |
| Max Patient Load (in Kgs) | 200 TO 250 KGS |
| Trendelenburg (in Degrees) | 25 DEGREE |
| Height Adjustable Range (in mm) | MIN 750 MM WITHOUT MATTRESS MAX.1000 MM WITHOUT MATTRESS |
| Application | Operation Theatre |
| Table Type | Fully Electric |
| Type of Surgery | Orthopedic |
| Country of Origin | Made in India |
| Brand | ARYAMED INDIA |
| Dimensions | LENGTH OF TABLE = 1900 MM , WIDTH OF TABLE TOP= 520 MM |
| Size | Large |
Technical Data:-
| LENGTH OF TABLE | 1900 MM |
| WIDTH OF TABLE TOP | 520 MM |
| MINIMUM HEIGHT (WITHOUT MATTRESS) | MIN.700 MM |
| MIXIMUM HEIGHT (WITHOUT MATTRESS) | MAX.950 MM |
| TRENDELENBURG | 25 DEGREE |
| REVERSE TRENDELENBURG | 25 DEGREE |
| LATERAL TILT | +-20 DEGREE |
| BACK SECTION | +-60 DEGREE |
| HEAD SECTION | +-60 DEGREE |
| LEG SECTION | 0 DEGREE-90 DEGREE |
| FLOOR LOCKING SYSTEM | MANUAL |
SPECIAL FEATURES:-
• We are providing first SMPS based control Box.
• Can handle better Voltage Fluctuations.
• When idle has zero current consumption and saves power, these are as per new
European and American Standards where the idle power consumption should
be zero and where Transformer based systems are outdated
• We are providing a Handset and Additional control panel
• Indication of Battery Back provided in the second handset.
• The Control panel has 2 memory functions.
• The second handset has also safety key to lock the complete handset
• The Handset is designed with Back LED Indicator for better visibility.
• This is the only handset with Backlight features
TABLE POSITIONS:-
• Height Adjustment – Up & Down
• Lateral Tilt – Left & Right
• Trendelenburg & Reverse Trendelenburg
• Flex Position & Reflex Position
SALIENT FEATURES:-
• Encentric Pillars • Stainless Fitting • Detachable, head, leg & Pelvic section • In built kidney bridge
• Five Sectional Radio – Translucent Top. • Base & Cover made of attractive, easy to clean Stainless
Steel. • Sophisticated mechanics provide smooth, step less articulation of the table Top
for precise patient positioning. • Standby Battery Back-up with recharging circuit.
OPTIONAL:-
- Floor Locking by Remote
- Low Height
- Manual Override
